Key Specifications
MAXIMUM POWER
20W, 100W, 1000WMAX CURRENT SOURCE/MEASURE RANGE
1A, 7A, 10AMAX VOLTAGE SOURCE/MEASURE RANGE
20V, 100V, 200V, 1100VMEASUREMENT RESOLUTION (CURRENT/VOLTAGE)
10fA - 1pA / 10nV - 100nVFeatures
Greatly accelerate throughput with built-in voltage/current sweep capabilities
SourceMeter instruments provide sweep solutions that greatly accelerate testing with automation hooks for additional throughput improvement. This is true whether you are performing sweeps on transistors, simply verifying connector integrity, characterizing device performance, or virtually any DC volt-amp characteristic with high precision.
Highlights
- Linear staircase sweeps
- Logarithmic staircase sweeps
- Custom Sweeps
Integrate with switching systems for fast, multipoint testing
The instruments in the SourceMeter family offer wide versatility, so they make great solutions for a variety of applications in many industries. For seamless integration in fast multipoint testing applications, combine a SourceMeter instrument with a Keithley switch system.
Highlights
- Test semiconductor devices
- Test circuit Protection devices
- Test optoelectronic components
- Use for accelerated stress testing
| Model | Channels | Power | Measurement Resolution (Current/Voltage) |
Max Voltage Source/ Measure Range |
Max Current Source/ Mesure Range |
|---|---|---|---|---|---|
| 2401 | 1 | 20W | 1pA/100nV | 20V | 1A |
| 2400 | 1 | 20W | 1pA/100nV | 200V | 1A |
| 2410 | 1 | 20W | 1pA/100nV | 1100V | 1A |
| 2450 | 1 | 20W | 10fA/10nV | 200V | 1A |
| 2460 | 1 | 100W | 1pA/100nV | 100V | 7A |
| 2461 | 1 | 1000W | 1pA/100nV | 100V | 10A |
| 2470 | 1 | 20W | 10fA/1000nV | 1100V | 1A |
SLIDE TO VIEW MORESeries models
2400
